HPLC Mobile Phase Filtration Membranes

Membranes Designed for the Stringent
Requirements of Mobile Phase Filtration

  • Membranes are identical in composition and quality to those used in Pall’s HPLC-certified Acrodisc® syringe filters
  • HPLC certification assures that the filters will not add artifacts to your analysis
  • GH Polypro membrane is the best choice for filtering mobile phases
  • PTFE membrane provides the ultimate in chemical compatibility for filtering harsh chemicals and HPLC mobile phases
“Pall Laboratory products are designed for laboratory applications only. This product is not approved for use in medical, clinical, surgical or other patient applications. If you require further assistance in product selection for your chosen application, please email us a question or call 1-800-521-1520."


도움이 필요하세요?
Ask a Question
* Required

설명

Membranes Designed for the Stringent
Requirements of Mobile Phase Filtration

  • Membranes are identical in composition and quality to those used in Pall’s HPLC-certified Acrodisc® syringe filters
  • HPLC certification assures that the filters will not add artifacts to your analysis
  • GH Polypro membrane is the best choice for filtering mobile phases
  • PTFE membrane provides the ultimate in chemical compatibility for filtering harsh chemicals and HPLC mobile phases
“Pall Laboratory products are designed for laboratory applications only. This product is not approved for use in medical, clinical, surgical or other patient applications. If you require further assistance in product selection for your chosen application, please email us a question or call 1-800-521-1520."

응용분야

  • Purification and degassing of mobile phase solvents used in liquid chromatography applications

규격사양

Filter Media

  • wwPTFE (water wettable PTFE), TF (PTFE, hydrophobic polytetrafluoroethylene), PVDF (hydrophilic polyvinylidene fluoride), and Nylaflo™ (hydrophilic nylon) membranes

Pore Size

  • 0.2 and 0.45 μm

Typical Thickness

  • wwPTFE Membrane
    • 0.2 μm: 280 μm (11.0 mils)
  • TF (PTFE) Membrane
    • 0.2 μm: 139 μm (5.5 mils)
    • 0.45 μm: 135 μm (5.3 mils)
  • PVDF Membrane
    • 0.2 μm: 140 μm (5.5 mils)
    • 0.45 μm: 127 μm (5.0 mils)
  • Nylaflo Membrane 0.2 and 0.45 μm: 127 μm (5.0 mils)

Maximum Operating Temperature

  • wwPTFE Membrane: 55 ºC (131 ºF)
  • PVDF, TF (PTFE), and Nylaflo Membranes: 100 ºC (212 ºF)

Minimum Bubble Point – Water

  • IPA: wwPTFE Membrane
    • 0.2 μm: 1 bar (100 kPa, 14.5 psi)
    • 0.45 μm: .63 bar (63 kPa, 9.1 psi)
  • PVDF Membrane
    • 0.2 μm: 2.3 bar (230 kPa, 34 psi)
    • 0.45 μm: 1.1 bar (110 kPa, 16 psi)
  • Nylaflo Membrane
    • 0.2 μm: 3.4 bar (340 kPa, 49 psi)
    • 0.45 μm: 2.6 bar (260 kPa, 37 psi)

Minimum Bubble Point - IPA, TF (PTFE) Membrane

  • 0.2 μm: 1.0 bar (100 kPa, 15 psi)
  • 0.45 μm: 0.4 bar (40 kPa, 6 psi)

종류

Membrane Filters

사용

Microfiltration, Solvent Filtration

적용분야

Mobile Phase Filtration

영역

Analytical QC
