Pasteurizer Replacement Filter Family product photo Primary L

Pasteurizer Replacement Filter Family

For Cold Filtration of Beer with CFS NEO Systems

Pasteurizer Replacement filter cartridges are a family of pre-filters and hydrophilic membrane filters designed for reliable retention of spoilage microorganisms for the filtration of beer in CFS NEO Systems.

Description

The Pasteurizer Replacement filter cartridge family was developed and validated for removal of beer spoilage microorganisms in CFS NEO Systems.

There are 6 family members providing reduction of microbial spoilage organisms in beer. Four of the cartridges are constructed from microbial removal membranes with defined integrity test value. Two of the cartridges are pre-filters designed not only to protect the selected downstream membrane filter but also aid in the removal of beer spoilage organisms. The single open ended (SOE) configuration is designed to fit into the sanitary housings on CFS NEO Systems to ensure effective microbial reduction and assembly integrity.

Pasteurizer Replacement filter cartridges are suitable for exposure to repeated hot water sanitization and in situ steam sterilization cycles for longer service life in CFS NEO Systems. The optimized support and drainage media materials, provide increased mechanical strength during operation, repeated hot water, chemical and steam sanitization and thus, consistently high throughput.

This filter is integrity testable. An in-situ and non-destructive integrity test can provide assurance of filter performance within minutes. Integrity tests help manufacturers avoid costly issues such as product contamination, product losses, reprocessing and production delays, as well as satisfying auditor requirements.

Learn more about the importance of Integrity Testing and microbial filtration.


Features Benefits
Cartridges resistant to numerous sanitization cycles
  • Process reliability
  • Economical operation
  • Consistent filtrate quality
Hydrophilic membranes
  • Easy to wet and integrity test
  • Microbial stabilization of beer
Validated with beer spoilage microorganisms
  • Brand protection
  • Increased process safety
Individually serialized cartridges
  • Full traceability
Integrity testable
  • Brand protection
  • Documentation for quality records


Quality

  • Cartridges are produced in a controlled environment
  • Manufactured according to ISO 9001:2008 certified Quality Management System
  • All final filters are 100% integrity tested before manufacturing release

Food Contact Compliance

Please refer to the Pall website www.pall.com/foodandbev for a Declaration of Compliance to specific National Legislation and/or Regional Regulatory requirements for food contact use.



* Required
Need Help?
Download Datasheet
Description

For Cold Filtration of Beer with CFS NEO Systems

Pasteurizer Replacement filter cartridges are a family of pre-filters and hydrophilic membrane filters designed for reliable retention of spoilage microorganisms for the filtration of beer in CFS NEO Systems.

Description

The Pasteurizer Replacement filter cartridge family was developed and validated for removal of beer spoilage microorganisms in CFS NEO Systems.

There are 6 family members providing reduction of microbial spoilage organisms in beer. Four of the cartridges are constructed from microbial removal membranes with defined integrity test value. Two of the cartridges are pre-filters designed not only to protect the selected downstream membrane filter but also aid in the removal of beer spoilage organisms. The single open ended (SOE) configuration is designed to fit into the sanitary housings on CFS NEO Systems to ensure effective microbial reduction and assembly integrity.

Pasteurizer Replacement filter cartridges are suitable for exposure to repeated hot water sanitization and in situ steam sterilization cycles for longer service life in CFS NEO Systems. The optimized support and drainage media materials, provide increased mechanical strength during operation, repeated hot water, chemical and steam sanitization and thus, consistently high throughput.

This filter is integrity testable. An in-situ and non-destructive integrity test can provide assurance of filter performance within minutes. Integrity tests help manufacturers avoid costly issues such as product contamination, product losses, reprocessing and production delays, as well as satisfying auditor requirements.

Learn more about the importance of Integrity Testing and microbial filtration.


Features Benefits
Cartridges resistant to numerous sanitization cycles
  • Process reliability
  • Economical operation
  • Consistent filtrate quality
Hydrophilic membranes
  • Easy to wet and integrity test
  • Microbial stabilization of beer
Validated with beer spoilage microorganisms
  • Brand protection
  • Increased process safety
Individually serialized cartridges
  • Full traceability
Integrity testable
  • Brand protection
  • Documentation for quality records


Quality

  • Cartridges are produced in a controlled environment
  • Manufactured according to ISO 9001:2008 certified Quality Management System
  • All final filters are 100% integrity tested before manufacturing release

Food Contact Compliance

Please refer to the Pall website www.pall.com/foodandbev for a Declaration of Compliance to specific National Legislation and/or Regional Regulatory requirements for food contact use.

Specifications

Materials of Construction

Table 1: Pre-Filters


Part Number Media and hardware description
AB4PAREG7WH4 All Polypropylene media and hardware construction
AB4PAREJ7WH4 All Polypropylene media and hardware construction


Table 2: Final Membrane Filters


Part Number Media and hardware description
ABN4PAREM7WH4 Nylon 6,6 filter media in a Nylon 6-10 filter construction
AB4PAREQ7WH4 Supor® Polyethersulfone filter membrane in a Polypropylene filter construction
ABN4PAREV7WH4 Nylon 6,6 filter media in a Nylon 6-10 filter construction
ABN4PAREY7WH4 Nylon 6,6 filter media in a Nylon 6-10 filter construction

Performance

Microbial Removal Rating


Test Organism Log Reduction Value (LRV)
Final Membrane
Filters
Serratia marcescens
(ATCC 14756)
Lactobacillus brevis
in beer
Pediococcus damnosus
in beer
ABN4PAREM7WH4 11 8.5 9
AB4PAREQ7WH4 8 8 7.5
ABN4PAREV7WH4 7.5 9 8
ABN4PAREY7WH4 6 8 8

Pre-filters
AB4PAREG7WH4 4 - -
AB4PAREJ7WH4 2.5 - -

Type
Systems
Use
Clarification, Polishing, Stabilization
Application
Clarification, Stabilization
