Profile® II Ink Jet Depth Filter Cartridges
For Pre and Final Filtration of Ink Jet Inks
Profile II Ink Jet depth filter cartridges are constructed from all-polypropylene components with ethylene-propylene O-rings. These absolute-rated depth filter cartridges have excellent compatibility with most ink systems where removal ratings from 0.3 to 10 µm are required. In addition, proven tapered-pore technology and a sanitary dual O-ring seal assure filter integrity and ease of use with a wide range of ink jet formulations.
Why choose Profile II ink jet depth filter cartridges?
A graded pore density means these ink filters provide longer service life and reduce the filtration cost per gallon/liter.
Additional benefits include:
- Provide consistent from batch-to-batch ink quality
- Permanently trap contaminants without affecting critical ink properties
- Remove oversized contaminants without stripping off colorants
- Enjoy a longer service life while maintaining low filtration costs
- Graphic arts ink formulation filtration
Operating temperature and maximum differential pressures in compatible fluids.1
|Operating Temperature||Maximum Differential Pressure|
|82 °C / 180 °F||1 bard / 15 psid|
|70 °C / 158 °F||2 bard / 30 psid|
|30 °C / 86 °F2||4.1 bard / 60 psid|
1 Fluids that do not soften, swell or adversely affect the filter or materials of construction.
2 Recommended filter changeout: 2.3 bard / 40 psi.
Typical Liquid Flow Rate versus Differential Pressure3
3 For liquids with viscosities differing from water, multiply the pressure drop by the viscosity in cP.
Figure 1 Graded pore structure
